Spline Grinders Matrix S 10 x 72 Inches

Product Description

Specification:

• MATRIX Model S10 x 1830 BROACH GRINDING MACHINE,



• Max length admitted between centres...... 1830 mm



• Max diameter admitted........ 254 mm



• Max diameter ground...... 152 mm



• Component root diameter serrated form only.. 10mm



• Standard grinding wheel diameter....... 203mm



• Grinding wheel speeds, variable..... up to 3000rpm



• Grinding wheel motor D.C...1.5KW



Description:

• Complete with:-



• 3 fully automatic programmed grinding cycles,



• which include wheel dressing with compensation.



• Straight-sided spline dresser type 82LD.



• Workhead fitted with 10T index plate, selection of various index plates & segments also available.



• Setting fixture 82P.



• Work steady.



• Wheel arbor.



• Guards.



• Coolant supply.
• M.S.E. centrifugal clarifier
