Machine Id | 1118 |
Model | GD 30 CNC |
Make | Mitsubishi |
Year | 1998 |
Dimensions |
|
Power |
|
Location |
|
Category | Gear Hobbers CNC |
Serial No |
|
Country |
|
Type of Machine | CNC Gear Hobbing Machine |
Weight | 0.0 |
Asking Price | onrequest |
One (1) - Model GD30CNC MITSUBISHI "CNCGear Hobbing Machine,
suitable for the cutting of spur and helical gears, pinions, splines, work-gears, and other work-pieces of similar profile up to 11.8(300mm) diameter, 16(400mm) face, and 3 DP (module 8) capability
EQUIPMENT / FEATURES:
Coolant supply system
Automatic hob head swivel/clamping device
Hob arbor power clamping device
Full enclosure for work area w/door interlock device
Direct drive hob spindle, and hydraulic work-table rotation backlash eliminator
One (1) hob arbor (1.25diameter)
Coolant guard door (Manual sliding type)
Double palm control
Work counter/Tool counter (Shown on CRT screen)
Work area light
Hydraulic and lubrication oil system with automatic temperature control
Magnetic chip conveyor (including chip box ~20tall)
Hydraulic part clamping device
Circuit breaker with ground fault circuit interrupter
Light in the control box
Double palm start buttons
Hob arbor set-up device
Hob spindle load indicator
Complete electrical equipment for 3-phase, 60 Hertz, 230 volts
Full machine documentation, operator's manual for machine & controller,
parts list, wiring & hydraulic diagrams
CNC control system (FANUC 18MB) with gear hobbing software with conversational dialogue and CRT, with electronic hand-wheel for all CNC controlled motions
The following five (5) axes are numerically controlled via servo-motors:
X-Axis (radial feed)
Z-Axis (axial feed)
C-Axis (table rotation)
Y-Axis (hob shift)
A axis (for hob head swivel)
B-Axis (is for hob spindle rotation)
Multiple Machining patterns to include:
Crowning
Tapering
Double Cut
1-3 Step Cluster Hobbing
Gash Milling
Minimum input increment
0.00004for "X", "Z", and "Yaxis
0.001º for "Caxis
0.001º for "Aaxis
Infinitely variable radial feed
Infinitely variable axial feed
Infinitely variable hob speed
Automatic incremental hob shift
Automatic hydraulic clamping of hob head assembly
Automatic powered hob head swivelling
Self-diagnosis function
Ladder logic diagnostics (Shows on CRT)
110 V (AC), 1 ampere outlet
Alpha-numeric manual data input keyboard with 9CRT
Hob speed indicator (shows on CRT)
Work and tool life counter (shows on CRT)
Cycle-end indicating lamp
Fully enclosed coolant guarding
Automatic calculation of cutting conditions
RS232C I/O interface
All Servo Motors are brushless, maintenance-free AC type drives
Maximum programmable dimensions:
Synchronized control axis:
Additional equipment
PRINCIPAL SPECIFICATIONS:
Center distance from hob spindle to work spindle
Maximum hob size:
Feed rate:
Rapid traverse
Motors:
Total Power Consumption 45 KVA
![]() |
