Gleason Hypoid Gear Tester Gleason 513

504mm capacity.

Automatic cycle,

automatic meshing .

Torque and speed control system.

Automatic backlash control.

Manual pinion cone search.

Automatic stamping.

Pendant control for all function.

Very good condition

Description :

Model Gleason no 503

Gear Outside Diameter Maximum 508mm

Pinion outside diameter maximum : 254mm

Offset 101.6mm

Pinion Spindle :

Diameter of taper hole at large end 3 29/32 inches

Taper per foot                                  3 9/64 inches

Depth of taper                                  3 inches

Depth of hole at small end from face of spindle   15.5 inches

Gear Spindle :

Diameter of taper hole at large end  2 19/64 inches, depth of taper 3 inches

Diameter of hole at small end 2.168 inches

Depth of hole at small end from face of spindle 8 inches
